A History of Geological Maps: I. From Outcrop to the first Map

March 23, 1769 marks the birthday of pioneering stratigrapher William Smith, who is also credited as author of the first modern geological map, however like many other great accomplishments also Smith’s idea of depicting the distribution of rocks on a topographic map didn’t materialize out of nowhere.

The German mining engineer Georgius Agricola (1494-1555) dedicated in his “De re metallica” (1556) -  an early  textbook on mining technologies – an entire chapter to the distribution of valuable rocks in earth’s crust. The written description is correlated with various figures, showing in a sort of combined landscape – section the distribution, thickness and direction inside the mountain of the mineralized veins.


Fig.1. Veins and mineral seams, figure from “De re metallica”, not a real map, however directions are given on the borders.

The idea of a real map of rock-distribution was proposed first in 1684 by the British physician and naturalist Martin Lister (1639-1712). Lister suggested that the distribution of the different soil types of the British landscape could accurately be represented on a topographic map.

The Soil might either be coloured, by variety of Lines, or Etchings; but the great care must be, very exactly to note upon the Map, where such and such Soiles are bounded…Now if it were noted, how far these extended, and the limits of each Soil appeared on a Map, something more might be comprehended from the whole, and from every part, then I can possibly foresee, which would make such a labour very well worth the pains.“

As – so Lister continues – the soil types correlate with the underlying bedrock, by mapping the soils one could also map the rocks hidden in the underground.

However Lister never realized a real map based on this theoretical premise. It was the Italian Count Luigi Ferdinando Marsili (1658-1730) who made the next important step. As military engineer Marsigli traveled widely in Italy, France, Germany, the Balkans and Turkey, creating topographic maps for military use of the visited countries. An exact representation of the landscape was essential to plan movements of an army or identify the best locations for fortifications. Marsigli became a keen observer
and a skilled cartographer of the landscape, sketching rock outcrops or  prominent features of the landscape. After an unfortunate military campaign in Germany, Marsigli was accused of cowardice, his military career ruined he used his acquired skills to create maps for more peaceful applications.


Fig.2. Section combined with a map of a silvermine, published in - "Mappa metalographica…[]" by Luigi Ferdinando Marsili, he added also some geological information (lower right corner) with a detailed rock-section - "Upper rock", "Vein" with mined "Ore" and "Lower Quartz".

In 1726 he published a map of the mining districts in Hungary and sketched the distribution of gypsum and sulfur deposits near his hometown Bologna (1717). In his sketch he connected the single gypsum quarries and outcrops along rivers with a shaded area, delimiting so the folded gypsum-bearing rocks. This map is important as it displays a first approach to the problem all geologists must face – not only documenting the visible outcrop of a rock or the position of a mine or quarry (such maps existed already), but interpolating the distribution of the not accessible part of  a geological formation.


Fig.3. The map from “Atlas et Description Minéralogiques de la France” (1780), by French pharmacist and botanist Jean-Étienne Guettard, shows the distribution of outcrops with minerals, fossils or rocks. Such mineralogical maps predate true geological maps, showing sites of geological interest, however lacking the interpolation between the single “data points” (image in public domain, originally posted by BibliOdyssey).

It may surprises that despite many naturalist had already produced very detailed descriptions and maps of single outcrops, almost nobody made a connection between sites with similar rocks. But not only was the unequivocal identification of geologic formations at the time still very difficult, many naturalists considered connecting single outcrops by a presumed (not visible at the surface) extension of the rocks as unscientific speculation. This aversion of early geognosts to geological maps is exemplified by the strange behavior of naturalist Jean-Étienne Guettard (1715-1786), famous for his detailed mineralogical and volcanological maps. Guettard in 1777, after eleven years of  hard work, abandoned the prestigious project by the French minister of Mining to produce a series of geological maps of France. He simply couldn’t overcome the idea that a map should represent only facts (in this case outcrops) – but a blank map with just some isolated spots of color wasn’t exactly what the French authorities wanted.

Maybe the first true geological map was drawn by an anonymous naval cartographer in 1757. In the outlines of the German island of Heligoland he added boundaries between four different rock types: Kreide (chalk), Muschelkalkstein (limestone), Bunter Sandstein (sandstone) and Kohle (coal beds). The map depicts the boundaries of the various geological formations even below the sea.

As the author, also the intended use of this map is unknown. The historian of geology  – David. R. Oldroyd – speculates that the map maybe could be used as aid to navigation, as sailors could determine their position by evaluating the rocks and sediments dredged from the seafloor.

To be continued…

Bibliography:

FRANCESCHELLI, C. & MARABINI, S. (2006): Luigi Ferdinando Marsili (1658-1730): A pioneer in geomorphological and archaeological surveying. In VAI, G.B. ed, The origins of geology in Italy: Geological Society of America Special Paper 411: 129-139
OLDROYD, D. (2013): Maps as pictures or diagrams: The early development of geological maps. In BAKER, V.R. ed, Rethinking the fabric of geology: Geological Society of America Special Paper 502: 41-101

Celebrating the Irish-Geological Heritage

According to a popular myth, long time ago lived a giant named Finn McCool on the shores of the county of Antrim in Ireland. On the opposite shores lived the Scottish giant Benandonner. One day Benandonner challenged McCool to a battle. McCool started to build a bridge, made of large columns of black rocks, to cross over the Irish Sea. Soon the bridge was completed and seeing his furious opponent approaching, Benandonner became afraid of the battle. So he asked advice to his wife. The wife responded “go hide in your bed and let me do the talking!” As McCool entered the castle, he asked astonished “who is this giant man snoring so loud in this bed?” The wife responded “Oh, it’s only our youngest, but my husband will be back soon. “ If this was the child, how big would be the father?! McCool started to run back to Ireland, destroying the bridge of columns behind him – so that’s why we today see ending the giant’s causeway in the middle of the sea.

As charming this account is, it is probably not a true myth but a story told for the first tourists visiting the site, as there is no mention of it in historic documents or collections of Irish folklore. Today the legendary formation of the “Giant’s Causeway” is understood much better. When the Antrim basalt started to cool down the crystallizing rock contracted in volume, forming joints resembling a hexagonal pattern on the surface of the former lava flow.
The first mention of the “Giant’s causeway” was published in an anonymous travel account in 1693. Travelling around the rural Irish landscape was an arduous task at the time and scholars intrigued by the first descriptions of this strange site preferred to send artists there, instructed to produce a realistic representation of the scenery. Apparently the first results were very deluding, as the scholar Reverend William Hamilton remarks in 1786:
Neither the talents nor the fidelity of the artist seem to have been at all suited to the purpose of the philosophical landscape . . . . In this true prospect, the painter has very much indulged his own imagination…[]

Fig.1. The first published image of the Giant’s Causeway by local artist Christopher Cole Foley was used to illustrate an account by Samuel Foley, Bishop of Down and Connor, in 1694. However both the drawing and the engraving from it were considered inadequate depictions of this peculiar Irish landscape.

The Dublin Society decided to offer an award for the most realistic and scientific accurate illustration of the Giant’s Causeway. In 1740 the prize was won by Dublin artist Susanna Drury, who spent three months along the Irish coast to study the landscape and produce two paintings (a view from the east and a view from the west) of the Giant’s Causeway. These paintings were used as reference for various later engravings and illustrations and significantly increased the interest of the people in this geologic formation, today one of the most popular landscape in Northern Ireland and designated as World Heritage site by the UNESCO in 1986.

Fig.2. An engraving of 1768 based on the original painting by Susanna Drury “East Prospect of the Giant’s Causeway”.

Bibliography:

DOUGHTY, P. (2008): How things began: the origins of geological conservation. From: BUREK, C. V. & PROSSER, C. D. (eds) The History of Geoconservation. Geological Society, London, Special Publications, 300:7-16

Forensic Geology and the Murder-case of Aldo Moro

Rome, March 16, 1678 a car of the type Fiat 128 suddenly braked midst of the street, prompting the following cars to crash onto it. A series of shots from a machine-gun followed, killing all of the five bodyguards of Italian prime minister Aldo Moro. The prime minister was kidnapped, days later the first messages from the Brigate-Rosse, a terrorist-association active at the time in Italy, arrived, causing a severe political crisis as the government was insecure how to deal with the terrorists demands. Time passed, letters and messages were exchanged, when on May 8, an anonymous telephone-call signaled a parked car of the type Renault 4 in the center of Rome.


Fig.1. Moro, photographed during his kidnapping by the Red Brigades.

Inside the car the Police found Aldo Moro, killed by a series of gunshots. Investigators immediately started to collect crime-scene evidence. During the autopsy small traces of sand were found inside Moro´s trouser cuffs, traces of geological material were also collected from the shoes and the trunk of the car, where the body was found. The forensic geologist had to answer two important questions: – could the geological evidence be tracked back to the site, where Moro was killed or his body dumped into the car? - could the geological evidence suggest an approximately time for when this happened?

The chemical composition of the sand grains was analyzed, so to may be able to identify the rocks from where the grains eroded. The grain-shape and -size distribution could help to identify the depositional environment of the sand. All the sand, from Moro´s clothing as from the interior of the car, was identical, suggesting that the body was dumped into the car where Moro was killed or at least imprisoned. It was loose sand, without cement between the single grains (so it was clear that it was not derived from an older sandstone), of uniform grain-size, very well sorted. The grains where also smoothed and rounded by constant abrasion, like it happens by the constant motion of waves. It was so easy to identify the material as recent beach sand. This identification was supported by the presence of marine shells and microfossils. The remains of marine organisms, living in shallow water, suggested that Moro was killed or imprisoned during his last days somewhere along the coastline near Rome.
The microfossils where identified as Miocene species, eroded from rock-outcrops not found along the coastline and transported by a river to the sea. This was an important discovery, as it suggested that the supposed crime-site was located near the delta of the river Tiber, the only river with a drainage basin where Miocene rocks were found. Also some grains of igneous rocks, recovered from the shoes, and eroded and transported from the volcanic hills surrounding the city of Rome, supported this hypothesis. Subsequent sampling showed that sand from an 11km long segment, situated north of the mouth of the Tiber, matched the sand found on Moro´s clothing.

Fig.2. Geological map showing the Tiber-delta and the volcanic cones of the Alban Hills, from “Carta Geologica per servire alla storia dei Vulcani del Lazio del Prof. Giuseppe Ponzi” (1874), from the collection of the Italian Geological Service, published September 5, 2014 on the blog http://www.geoitaliani.it. The coastline of the Italian province of Latium is characterized by sedimentary rocks and recent river and marine deposits. The inland is formed by volcanic rocks, dated to the Pliocene.

There were only few streets in this area and indeed traces of asphalt were found on the tires of the car. However more careful analysis reveled that the asphalt was of very poor quality and comparison with sand-samples revealed that it was in fact unrefined bitumen, derived from the pollution of a nearby oil-tanker terminal, washed ashore and mixed into the sand. Traces of this kind of bitumen were then found also inside the car, Moro´s kidnappers  walked on the contaminated sand not long before the car was found, as the smears of bitumen were still fresh. This last observation suggested that Moro was killed shortly before the telephone-call and the discovery of the body.

More close investigation showed that on the shoes, below the layer of beach sand, there was also a layer of volcanic soil. Applying the principle of sedimentary superposition (as the soil-layer is covered by the sand, it must be older), the forensic geologists suggested that Moro was imprisoned, before being relocated to the shore, somewhere inland, may south-east of Rome, where on easily erodible volcanic rocks clay-rich soils formed over time. Pollen grains supported this reconstruction, as the pollen in the soil came from Cypress and Hazel, blooming late in winter, but there was no trace of plants blooming in early spring (after March-April, so Moro the last weeks before his murder couldn´t been there). Only years later the investigators found an apartment, in the south-eastern suburbs of Rome, where Moro probably was hold captive for some time.

Various suspected murders were arrested during a raid against the Brigate Rosse. Based on various partial confessions the crime was reconstructed as follows:

The bodyguards were killed by a commando, hiding along the street where another terrorist blocked with his car Moro´s convoy. Moro was then kidnapped and hold captive for 55 days in the anonymous apartment near Rome, where he was finally forced into the trunk of the car and executed. The car was then parked in the center of Rome and a kidnapper called the police.

But what about the found beach sand? The kidnappers claimed to have tried to mislead the investigators by faking evidence, pouring some saltwater and sand onto the victim and into the car. However to fake all the traces found on the car (especially the smears of bitumen) and on Moro´s shoes all those object had to be there on the shore – why such efforts to create evidence most people wouldn´t even realize exist?

The supposed prison along the coastline was never found. Are the kidnappers with their misstatements hiding something, maybe a land property on the shore belonging to an important person?
After five lengthy court proceedings and more than 37 years later still many questions remain unanswered...
